BH Quartz 1.5 Bicycle Overview
The BH Quartz 1.5 is a high-performance aluminum frame race bike designed for road cycling enthusiasts. It features upper mid-range components and hydraulic disc brakes for optimal control and performance on the road. This bike is ideal for riders looking for a reliable and efficient road bike that offers a smooth and responsive ride.
Key Features of BH Quartz 1.5
Frame Material: Aluminum
Fork Material: Carbon
Brake Type: Hydraulic Disc
Shifting: Mechanical
Drivetrain: 2 × 11
Wheel Size: 700c
Groupset: 105, FSA
Wheel Material: Aluminum
Category: Road
Subcategory: Race
Price: 1.899 € (RRP)
BH Quartz 1.5 Specifications
| Component | Description |
|---|---|
| Saddle | San Marco Monza Start |
| Brakes | Front: Shimano 105 hydraulic, Rear: Shimano 105 hydraulic |
| Shifters | Shimano 105 Hydraulic |
| Cassette | Shimano 105 11/34 |
| Rear Derailleur | Shimano 105 11sp |
| Tires | Hutchinson Nitro2 700x28 |
| Chain | FSA TH-CN1102 |
| Headset | BH Lite 1.5" |
| Crank | FSA Vero Pro 46/36, X, Crank set, FSA Vero Pro 46/36, SM 170mm, MD 170mm, LA 172,5mm, XL 172,5mm |
| Rims | Shimano RS170 |
| Fork | Quartz Disc, Integrated Carbon 1.5" |
| Front Derailleur | Shimano 105 |
| Handlebar | BH Lite Compact, X, Handlebar, BH Lite Compact, SM 420mm, MD 420mm, LA 440mm, XL 440mm |
| Seatpost | BH Lite 27.2 |
| Frame | Quartz Disc Aluminium 6061, Thru Axle 12mm |
| Stem | BH SL, X, Stem, BH SL, SM 80mm, MD 80mm, LA 100mm, XL 110mm |
BH Quartz 1.5 Geometry and Sizing
The BH Quartz 1.5 is available in multiple frame sizes to accommodate riders of different heights. Here are the key geometry details for each size:
XS Size:
- Top Tube Length: 530mm
- Head Tube Angle: 72.5°
- Head Tube Length: 115mm
- Seat Tube Angle: 74°
- Chainstay Length: 428mm
- Seat Tube Length: 480mm
- Rider Height Range: 156-166cm
SM Size:
- Top Tube Length: 543mm
- Head Tube Angle: 72.5°
- Head Tube Length: 140mm
- Seat Tube Angle: 74°
- Chainstay Length: 428mm
- Seat Tube Length: 500mm
- Rider Height Range: 163-174cm
MD Size:
- Top Tube Length: 557mm
- Head Tube Angle: 73°
- Head Tube Length: 165mm
- Seat Tube Angle: 73°
- Chainstay Length: 428mm
- Seat Tube Length: 520mm
- Rider Height Range: 171-182cm
LG Size:
- Top Tube Length: 570mm
- Head Tube Angle: 73°
- Head Tube Length: 185mm
- Seat Tube Angle: 72.5°
- Chainstay Length: 428mm
- Seat Tube Length: 540mm
- Rider Height Range: 179-189cm
XL Size:
- Top Tube Length: 583mm
- Head Tube Angle: 73°
- Head Tube Length: 200mm
- Seat Tube Angle: 72.5°
- Chainstay Length: 428mm
- Seat Tube Length: 560mm
- Rider Height Range: 185-195cm
Overall, the BH Quartz 1.5 offers a range of frame sizes to ensure a comfortable and efficient riding experience for cyclists of various heights.
Pros and cons of bh quartz 1.5
| Pros | Cons |
|---|---|
| Lightweight aluminum frame | May not be as durable as a steel frame |
| Shimano 105 groupset for smooth shifting | May require frequent maintenance |
| Carbon fork for added comfort | May not be suitable for rough terrain |
| Disc brakes for reliable stopping power | May be more expensive compared to other models |
| Comes in a variety of sizes for different riders | May not have as many customization options |
Reviews of bh quartz 1.5 owners
| Name | Review |
|---|---|
| John | The BH Quartz 1.5 is a great bike for the price. It's lightweight and handles well on various terrains. I highly recommend it. |
| Sarah | I've been using the BH Quartz 1.5 for a few months now and I'm impressed with its performance. It's comfortable to ride and has a smooth gear shifting system. |
| Mike | This bike exceeded my expectations. The build quality is top-notch and it's a joy to ride. I'm very satisfied with my purchase. |
| Emily | I love my BH Quartz 1.5! It's a reliable and durable bike that has held up well to regular use. It's definitely worth the investment. |
| Chris | The BH Quartz 1.5 is a fantastic bike for both beginners and experienced riders. It's versatile and offers a smooth riding experience. I couldn't be happier with my purchase. |
